| Mfr | Würth Elektronik Midcom |
| Series | WE-CHSA |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.417" L x 0.417" W (10.60mm x 10.60mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Drum Core, Wirewound |
| Operating Temperature | -55°C ~ 150°C |
| DC Resistance (DCR) | 8.7mOhm Max |
| Frequency - Self Resonant | 50MHz |
| Ratings | AEC-Q200 |
| Current - Saturation (Isat) | 17.8A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | 1011 |
| Height - Seated (Max) | 0.445" (11.30mm) |
| Inductance | 3.9 µH |
| Current Rating (Amps) | 11.2 A |
