| Mfr | Würth Elektronik Midcom |
| Series | WE-CHSA |
| Package | Tape & Reel (TR) |
| Product Status | ACTIVE |
| Tolerance | ±20% |
| Package / Case | Nonstandard |
| Size / Dimension | 0.480" L x 0.480" W (12.20mm x 12.20mm) |
| Mounting Type | Surface Mount |
| Shielding | Shielded |
| Type | Drum Core, Wirewound |
| Operating Temperature | -55°C ~ 150°C |
| DC Resistance (DCR) | 15mOhm Max |
| Frequency - Self Resonant | 30MHz |
| Ratings | AEC-Q200 |
| Current - Saturation (Isat) | 12.1A |
| Material - Core | Ferrite |
| Inductance Frequency - Test | 100 kHz |
| Supplier Device Package | 1212 |
| Height - Seated (Max) | 0.474" (12.05mm) |
| Inductance | 8.2 µH |
| Current Rating (Amps) | 8.8 A |
